(Problem of Discharging)


Silo Discharge Systems

IIOEC has encountered and conquered every discharge problems. This knowledge and experience has been brought together to provide the most comprehensive range of discharge devices available from a single manufacturer. The aim is always to offer effective and innovative process solutions to solve particulate solids discharge problems.

The IIOEC range of discharge systems includes:

1- Rotary feeder discharger
2- Screw discharger
3- Bin activator with vibration motor
4- Aerator pads
5- Air sweeper
6- Fully fludized cone OR air fludizing pads
7- Multi air nozzles

Solving a vessel discharge problem with a particulate solid is not just a matter of fitting a discharge device. To ensure the total process parameters are met then selection has to be based on:

1- Material characteristics
2- Vessel Geometery
3- Downstream equipment
4- Overall process application

Every product has different handling characteristics when stored in a silo or hooper. Typically, differences arise from:

1- Bulk density
2- Particle size & distribution
3- Particle shape
4- Shear properties
5- Moisture content
6- Temperature
